KHS 6600
$4,589.00
Details
- 12-speed
- 4-Bar Horst Link Carbon frame
- WTB tubeless-ready wheels
- Fox Float fork & shock
- 4-Bar Horst Link Carbon frame
- Shimano SLX rear derailleur
- Shimano CN-M6100 chain
- FSA Mega EXO BB
- Shimano CS-M6100, 10-51T cassette
- Shimano M420 4-Piston hydraulic disc brakes
Wheel size:
- Size Small: 27.5-inch
- Sizes Medium – X-Large: 29-inch
Specs
| Frame | MSD Full Carbon 4-Bar Horst Link, 29/650B+, 135mm, 1.5 Taper, 12 x 148 Boost Rear Axle, w/Replaceable Derailleur Hanger |
|---|---|
| Fork | FOX Float 36, 29 Std/27.5+ Evol Air, Rhythm, 150mm, Grip Sweep Adj., Ext Rebound Adj., 1-1/8~1.5 Taper, 15mm x 110 QR Boost |
| Rear Shock | FOX Float DPS, Performance, 3-Pos, Evol w/LV Eyelet |
| Rims | WTB ST=S:i35, M-XL:i29 TCS, Disc, Double Wall, 28H, Tubeless-Ready |
| Hubs |
Front: Shimano HB-MT410, CenterLock Disc, 15mm x 110mm, Boost Rear: Shimano FH-MT410-B Disc Cassette, 12 x 148mm, Boost |
| Spokes | 14/15G Double Butted Stainless, Black w/Aluminum Nipples, 28x28 |
| Tires | Kenda Regolith Pro, S: 27.5 x 2.6", M-XL: 29 x 2.4", 120TPI, Folding, Tubeless-Ready |
| Bottom Bracket | FSA MegaExo Outboard Cartridge Bearing |
| Crankset | FSA Gamma Pro, 2-pc., 30T Megatooth, Boost, PF92, S: 170, M-XL: 175 |
| Shifters | Shimano SLX, SL-M7100, 12s, Trigger, Right Only, I-Spec EV |
| Rear Derailleur | Shimano SLX, RD-M7100 |
| Cassette/Freewheel | Shimano CS-M6100, 10-51T, 12-Speed |
| Chain | Shimano CN-M6100 |
| Brakes | Shimano MT420 4-Piston Hydraulic Disc,180/160mm Rotors= RT64 CenterLock |
| Brake Levers | Shimano M4100, I-Spec EV |
| Handlebars | FSA Grid 35mm, 800mm x 20mm |
| Tape/Grips | Q2 Lock-on |
| Stem | FSA Grid 3D Forged, 35mm |
| Headset | FSA No. 57/52, Zero Stack, 1-1/8"~1.5 |
| Seatpost | Kind Shock Exa-Form KSP-900-i, Integra w/Remote, Travel Adjust, 31.6mm |
| Saddle | WTB High Tail, CrMo Rail |
| Pedals | Sold separately |
* Subject to change without notice.
Part Numbers
| Option | UPC | MPN | Store SKU |
|---|---|---|---|
| Raisin / Small / 27.5-inch | 756928919800 | 911740000 | 660153871661 |
| Raisin / X-Large / 29-inch | 756928919831 | 911740003 | 660161574761 |
